China Top10 Oem&ODM Custom PCB/PCBA Circuit Board Fr4 94V0 Rohs Electronic Circuit Pcb Board Manufacturer

Short Description:


  • Order Requests: Qty. PCB Specification.
  • Necessary Files: PCB Gerber, BOM, Pick&Place Files
  • Others: Assembly drawings, Other requirements
  • Product Detail

    Product Tags

    PRODUCT SPECIFICATION:

    Base Material: FR4-TG140 Surface Finish: HASL(Lead Free)
    PCB Thickness: 1.6mm Solder Mask: Green
    PCB Size: 10*18mm Silkscreen: White
    Layer Count: 1/L Cu Thickness 35um(1oz)

    What files are required to produce your PCBs:

    1. PCB files (Gerber files).

    2. The specific quantity.

    3. PCB thickness,Material, Copper thickness, Surface finish,Solder mask color or any other requirements.

    For PCB assembly, the more files are required as below:

    1. Bom list (bill of material)

    2. Centroid files (Pick & Place files)

    3. Assembly drawings,

    4. Extra requirement for assembly.

    Surface Finish Process:

    pcb61

    ENIG(Immersion Gold):

    Immersion gold process deposits a nickel- gold coating with stable color, good brightness, flat coating and good solderability on the surface of the printed circuit, the cost is relatively more expensive.

    pcb67

    HASL (Lead Free):

    The flatness is insufficient, but HASL is low cost. Due to environmental protection requirements, there is a requirement for lead free.

    HASL (Lead Free) process is widely used by customers.

    pcb59

    OSP:

    Cover a layer of anti- oxidation protective film on the copper surface, the film thickness is uniform, the cost is low, but it is difficult to withstand multiple soldering.

    WHY US:

    1. Lower your cost: Turnkey PCBA Assembly; BOM Solution To Reduce The Cost; Professional Advice For Your Design Optimization.

    2. Quality Assurance: ISO14001,IATF16949,UL Certificated; 100% AOI/E-Testing/X-ray/Software Programming and Function Test Supported.

    3. On Time Delivery: Real- time Order Status Update; Transparent Production process Step; 99% On- time Shipping By DHL/ UPS/ FeDex/ TNT.

    4. Best Customer Service: 24 Hours Online; Timely After- sales Feedback In 12 Hours; Professional Technical Support.

    Main Product:

    We’ve exported PCBs for more than ten years,support both prototyping and mass production.

    1. 1- 32 Layer PCB Production(No MOQ.)FR-4, FPC board ,Aluminum plate,Heavy copper,HDI.

    2. Components Sourcing.

    3. Quick- turn Prototype and SMT&THT Assembly with high quality.

    4. Precision Metal Parts Machining.

    2.2

    PCB Capabilities:

    Layer Counts 1- 32 layers
    Base Material FR- 4, Polyimide, Metal base (Aluminum, Copper), High Frequency (Rogers, Teflon,PTEE), Hybrid, etc.
    PCB Type FR- 4 Rigid PCB, Aluminum PCB, Copper- based PCB, HDI, FPC, Rigid- Flex PCB, High- Frequency PCB, Rogers PCB, Thick copper PCB, Halogen- Free PCB, etc.
    PCB Thickness 0.1mm- 10mm
    Copper Thickness 1/ 2oz-6oz (18um-210um)
    Board size 500mm * 1500mm
    Min Tracing/Spacing 0.075mm/ 0.075mm (3mil/ 3mil)
    Min drilling Hole Mechanical drilling: 0.15mm (6mil), Laser drilling: 0.1mm (4mil)
    Solder Mask Green, Matt Green, Black, Matt Black, White, Red, Yellow, Blue, Purple, etc.
    Silkscreen color White, Blue, Black, Red, Yellow
    Surface finish HASL (Lead- free), Immersion Gold (ENIG), Immersion Tin, Immersion Silver, OSP, Carbon oil, etc.
    Special Techniques Impedance Control, Gold Fingers, Blind/ Buried vias PCB, Peelable solder mask, Half- holes, Via- in- Pad and Countersink hole, etc.

    If you need to prototype your PCB, Pls send your PCB Files (Gerber files) to sales@fljpcb.com

    PHILIFAST offers high- quality PCB circuits board fabrication and SMT assembly service, our professional engineer team serve thousands of customers from all over the world, Whether it is an sample order or large volume production runs, we strive to satisfy each of our customers and give our customers the best purchase experience.

    Also, We focus on turnkey service to help customers integrate the whole project.
