flexible pcb 6 Layer fpc Flexible-Rigid PCB manufacture Flex PCB Cable (FPC) Rigid-Flexible pcba assembly

Short Description:

Product Detail

Product Tags

PRODUCT SPECIFICATION：

Base Material:	FR4&PI	Surface Finish:	ENIG
PCB Thickness:	1.6mm	Solder Mask:	Green/Yellow
PCB Size:	90*110mm	Silkscreen:	White
Layer Count:	6/L	Cu Thickness	35um(1oz)

PHILIFAST produce PCBs for our customers working in frequency ranges from LED products to communication equipment and in industries as diverse as Medical devices through to automotive, aerospace and Bluetooth etc.

Main Product:

FPC Application:

1. Camera, digital camera, DV

2. Printer, fax machine, scanner

3. Laptop, LCD screen, CD-ROM drive, hard disk, HDD

4. Recorder head, laser bald, VCD, DVD

5 Car, car DVD, auto meter, GPS

6. Aerospace, satellite

7. Medical equipment

8. Instrumentation

FPC Application:

1,PCB Fabrication (1-32L PCB, FR-4, Alu-base PCB, TEFLON, Rogers, HDI PCB)

2,Flexible PCB, Rigid-Flex PCB.

3,PCB Assembly (SMT, BGA, DIP)

4,Parts Sourcing

5,IC program with HEX file.

6,Final Functional Testing.

7,PCB & PCBA Copy/Clone Service.

8,PCB enclosure

9,PCB Stencil

10,Finish product assembly

FPC&Flex-Rigid Circuit Board:

NO.	Item	Prototype	Mass Production
1	Layer Count	Flex Board:1-6 L,Flex-Rigid Board: 2-12 L	Flex Board:1-6 L,Flex-Rigid Board: 2-12 L
2	Max Panel Size	≤500X500mm	≤500X500mm
3	Base Material Type	FR-4,Pl,,CCL,PET, PEN	FR-4,Pl,,CCL,PET, PEN
4	Max Board Thickness	Flex Board≤2.0mm, Flex-Rigid Board≤4.0mm	Flex Board≤2.0mm, Flex-Rigid Board≤3.0mm
5	Min Board Thickness	Flex Board≥0.05mm, Flex-Rigid Board≥0.3mm	Flex Board≥0.05mm, Flex-Rigid Board≥0.4mm
6	Min Line Width	≥ 0.05mm(2mil)	≥0.075mm(3mil)
7	Min Line Space	≥ 0.064mm(2.5mil)	≥0.075mm(3mil)
8	Min Through hole	0.15mm(6mil)	0.15mm(6mil)
9	Min Blind hole	0.1mm(4mil)	0.1mm(4mil)
10	Min Buried Hole	0.2mm(8mil)	0.2mm(8mil)
11	Min Plated Hole Thickness	20µm(0.8mil)	20µm(0.8mil)
12	Surface coating	HASL,ENIG, OSP,ENIG+OSP	HASL,ENIG, OSP,ENIG+OSP
13	Solder Mask color	Green,Blue,Black,White,Yellow,Red	Green,Blue,Black,White,Yellow,Red
14	Silkscreen color	White,Black,Red	White,Black,Red
15	Thick Copper	1/3oz - 2oz (12-70µm)	1/3oz - 2oz (12-70µm)
16	PTH Dia Tolerance	±0.076mm(±3mil)	±0.076mm(±3mil)
17	NPTH Dia Tolerance	±0.05mm(±2mil)	±0.05mm(±2mil)
18	Outline Tolerance	±0.15mm (±6mil)	±0.15mm (±6mil)
19	Test Voltage	50-330V	50-330V
20	Other Inspection item	IPC-6012 / A-600H	IPC-6012 / A-600H

PHILIFAST produce and assembly PCBs as per customer’s design files, we do not design pcb itself. If you have any inquiry,please send your design to us for quote.we’ll be your best EMS vendor.
