Turnkey Custom PCB SMD/DIP Fully Assembly Electronic Printed Circuit Board PCB Manufacturer Multi-layer FR4 1.6mm Immersion Gold Blue Solder Mask PCB Board

Short Description:

Order Requests: Qty. PCB Specification.

Necessary Files: PCB Gerber, BOM, Pick&Place Files

Others: Assembly drawings, Other requirements

Product Detail

Product Tags

Base Material:	FR4-TG150	Surface Finish:	ENIG
PCB Thickness:	1.6mm	Solder Mask:	Blue
PCB Size:	90*160mm	Silkscreen:	White
Layer Count:	4/L	Cu Thickness	35um(1oz)
Mounting Type：	SMT+DIP	SMT Package	0201,BGA, QFN
Testing Service	AOI,X-Ray,Function Test	Application	Controller Mainboard

Turnkey PCB Sevices:

1. PCB fabrication

(PCB Gerber files,Other requirements)

2. Turnkey PCBA: PCB+components+SMT and through-hole assembly+enclosure molding&housing

(BOM files, Pick&Place, Assembly Drawings,..)

PCB Fully Assembly :

Our Advantage:

1, Programming and Functional test

2, IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.

3, Professional service. ISO SMT and through hole assembly, over 10 years experience.

4, Certification: 94v-0, CE, SGS, FCC, RoHS, ISO9001:2008, ISO14001

5, Warranty period for PCBA: 2 years.

PCB ASSEMBLY CAPABILITY:

Turnkey PCBA	PCB+components sourcing+assembly+package
Assembly details	SMT and Thru-hole,PCB enclosure assembly
Lead Time	Prototype: 10-12 working days. Mass order: 18~20 working days
Testing on products	Flying Probe Test,E-Testing, X-ray Inspection, AOI Test, Functional test
Quantity	Min quantity: 1pcs. Prototype, small order, mass order
Files type	PCB: Gerber files(CAM, PCB, PCBDOC)
	Components: Bill of Materials(BOM list)
	Assembly: Pick&Place file, Assembly drawing
PCB Panel Size	Min size: 0.250.25 inches(66mm)
PCB Panel Size	Max size: 2020 inches(500500mm)
PCB Solder Type	Water Soluble Solder Paste, RoHS lead free
Components details	Passive Down to 01005 size
	BGA and QFN For Chip
	Double-sided SMT Assembly
	Fine Pitch to 0.8mils
	Part Removal and Replacement
Component package	Cut Tape,Tube,Reels,Loose Parts

PCB CAPABILITY:

1	Layers	1-32 Layer
2	Board material type	FR4,Ceramic substrate board,aluminum based board, high-Tg, Rogers and more
3	Compound material lamination	4 to 6 layers
4	Maximum dimension	600 x 1200mm
5	Board thickness coverage	0.2 to 6.00mm
6	Minimum line width	3mil
7	Minimum line space	3mil
8	Outer layer copper thickness	8.75 to 175µm
9	Inner layer copper thickness	17.5 to 175µm
10	Drilling hole diameter (mechanical drill)	0.25 to 6.00mm
11	Finished hole diameter (mechanical drill)	0.20 to 6.00mm
12	Hole diameter tolerance (mechanical drill)	0.05mm
13	Hole position tolerance (mechanical drill)	0.075mm
14	Laser drill hole size	0.10mm
15	Board thickness and hole diameter ratio	10:1
16	Solder mask type	Green, Yellow, Black, Purple, Blue, White and Red
17	Minimum solder mask	Ø0.10mm
18	Minimum size of solder mask separation ring	0.05mm
19	Solder mask oil plug hole diameter	0.25 to 0.60mm
20	Impedance control tolerance	±10%
21	Surface finish	HASL(Lead Free), ENIG, immersion silver, gold plating, immersion tin and gold finger

Fast Delivery:

PCB In 12Hours
PCBA In 3Days

Main Products Application:
*Medical Products
* Automotive Products
* Industrial Products
* Communication Products(AVL/GPS/GSM Devices)
* Consumer Electronics.

PCB Assembly Procedures:

* Program Management
PCB Files → DCC → Program Organizing → Optimization → Checking
* SMT Management
PCB Loader → Screen Printer → Checking → SMD Placement → Checking → Air Reflow → Vision Inspection → AOI → Keeping
* PCBA Management
THT→Soldering Wave (Manual Welding) → Vision Inspection → ICT → Flash → FCT → Checking → Package → Shipment

PHILIFAST provides you the best PCB manufacture and assembly experience
